VIGI InSight S655I

ข้อมูลจำเพาะของฮาร์ดแวร์

CAMERA

Image Sensor

1/2.7” Progressive Scan CMOS

Shutter Speed

1/3 to 1/10000 s

Slow Shutter

Yes

Minimum Illumination

Color: 0.01 Lux; 0 Lux with IR light

Day/Night Mechanism

IR Cut Filter

Day/Night Switch

Unified/ Scheduled/ Auto



LENS

Type

Fixed Focal Lens

Focal Length

1.44 mm

Aperture

F2.0

FOV

Horizontal FOV: 180°, Vertical FOV: 180°, Diagonal FOV:180°

Lens Mount

M12*P0.5

DORI Distance

Detect: 28.8 m (94 ft)
Observe:12 m (39 ft)
Recognize: 5.7 m (19 ft)
Identify: 2.8 m (9 ft)



Fisheye Display

Installation

Ceiling Mount; Wall Mount; Pendant Mount§

Display Mode

On VIGI VMS:
• Ceiling Mount:
Fisheye, AR Dewarp, 180 Panorama, 360 Panorama, Cylinder, 2PTZ, 4PTZ, Fisheye + 8PTZ, Fisheye + 3PTZ, 360 Panorama + 8PTZ, 360 Panorama + 6PTZ, 360 Panorama + PTZ
• Wall Mount:
Fisheye, 360 Panoramic Unwrap, 360 Panoramic Unwrap+3PTZ, 360 Panoramic Unwrap+8PTZ, 4PTZ, Fisheye + 3PTZ, Fisheye + 8PTZ

On VIGI App:
• Ceiling Mount:
Fisheye, 180 Panorama, 360 Panorama, Fisheye+3PTZ, 4PTZ, Cylinder, AR Dewarp
• Wall Mount:
Fisheye, 360 Panorama Unwrap, Fisheye+3PTZ, 4PTZ, 2PTZ, AR Dewarp



Angle Adjustment (Manual)

Range

N/A



ILLUMINATOR

IR LED

• Quantity: 4
• Range: 10 m
• Wavelength: 850 nm

White LED

N/A

Illuminator On/Off Control

Auto/Scheduled/Always on/Always off



VIDEO

Max. Resolution

2560x1920

Main Stream

• Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

• Resolution:
2560x1920, 2256x1696, 2048x1536, 1280x960

• Note:
If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
If WDR is on, the frame rate only supports up to 15fps.

Sub-Stream

• Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

• Resolution:
640x480, 320x240

• Note:
If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
If WDR is on, the frame rate only supports up to 15fps.

Bit Rate Control

CBR, VBR

Video Compression

• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264

H.264 Type

High Profile

H.264+

Main Stream Supported

H.265 Type

Main Profile

H.265+

Main Stream Supported

Video Bit Rate

• Main Stream: 256 Kbps to 6 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps




Image Settings

• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR,
• White Balance
• Prevent Overexposure to Infrared Light
• HLC Adjustable by Client Software

Image Enhancement

BLC/3D DNR/HLC/SmartIR

Wide Dynamic Range

120 dB

SNR

≥ 52 dB

Image Parameters Switch

Yes

Privacy Mask

Up to 4 Masks

ROI

1 Region

OSD Setting

Yes



AUDIO

Audio Communication

Two-Way Audio

Audio Input

Yes

Audio Output

Yes

Audio Compression

Yes

Audio Sampling Rate

8 KHz

Environment Noise Filtering

Yes

Audio Bit Rate

64 Kbps (G.711 alaw)



NETWORK

Protocol

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, 802.1x

ONVIF

Yes

API

Open Network Video Interface (Profile S/T/G)

Simultaneous Live View

3 Main Streams & 3 Sub-Streams

Client

Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS

Web Browser

• Google Chrome® 57 and above
• Firefox® 52 and above
• Safari® 11 and above
• Microsoft® Edge 91 and above

Cloud

Yes

Security

Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication



ALARM AND EVENT MANAGEMENT

Smart Event

• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Abnormal Sound Detection

Basic Event

• Motion Detection
• Video Tampering Detection
• Exception ( Illegal Login)

Alarm Linkage

• Memory Card Video Recording
• Message Push
• Audible Warning
• Email Alarm
• Upload Capture to FTP



INTERFACES

Network Interface

1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE

Alarm

N/A

Reset Button

Yes

Power

DC Power Port

On-board Storage

Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB§

Built-in Microphone

Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera

Built-in Speaker

Yes

Audio

N/A



GENERAL

Operating Temperature

-30 to 60 °C

Storage Temperature

-40 to 60 °C

Operating Humidity

95% or Less (Non-Condensing)

Storage Humidity

95% or Less (Non-Condensing)

Package Content

• VIGI Network Camera
• Quick Start Guide
• Waterproof Cable Attachments
• Mounting Accessories

Material

Metal

Net Weight

• 0.44 Kg ( without Mounting Accessories)
• 0.48 Kg ( with Mounting Accessories)

Power Supply

• 12V DC ± 5%, Max. 11.76 W, 5.5mm Coaxial Power Plug
• PoE: 802.3af/at, class 0, Max. 12.14W

Protection

IP67 Weatherproof, IK10 Vandal Proof

Product Dimensions (L x W x H)

5.2 × 5.2 × 2.2 in (132 × 132 × 56 mm)

Certifications

CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF
